Shoimage SHO-PXD Series Portable x-ray machine
Discover the Shoimage SHO-PXD Series Portable X-ray machine, designed for superior medical diagnostics right at your fingertips. Ideal for various medical uses, this lightweight and efficient device ensures high-quality imaging and ease of mobility. As an authorized distributor, Winselluma guarantees authenticity and unparalleled access to this cutting-edge technology, reinforcing our commitment to your healthcare needs. Trust Winselluma's expertise to elevate your medical imaging solutions.
Product Info
SHO-PXD Series – Deluxe Portable X-ray Machines
Models: SHO-PXD01 | SHO-PXD02 | SHO-PXD03
Product Overview
The SHO-PXD Series is a high-end portable X-ray system designed for medical, veterinary, and mobile diagnostic applications. The series combines:
-
Wired 17×17 inch FPD (Flat Panel Detector)
-
10.4-inch color touchscreen
-
Adjustable deluxe trolley with laptop stand and FPD box
-
15.6-inch Dell laptop workstation
Exposure can be triggered via wired hand brake, wireless remote, or touchscreen button, providing maximum flexibility, ease of use, and minimizing patient movement.
Key Features
-
Deluxe Adjustable Trolley with Laptop Stand and FPD Box
-
High-Resolution Wired FPD: 17×17 inch, Iray Venu1717X
-
Integrated Workstation: Dell 15.6" Full HD laptop with i5 processor, 32GB RAM, 512GB SSD, Windows 11 Home
-
Multiple Exposure Modes: Wired hand brake, wireless remote, touchscreen button
-
Battery Operation (SHO-PXD02): Supports portable use without AC power
-
Easy Deployment: Quick setup, minimal space requirement
-
Trolley Height Adjustable Range: 515–1810 mm from spot to floor
Technical Specifications
Specification SHO-PXD01 SHO-PXD02 SHO-PXD03 Power 5 kW 5.6 kW (with battery) 8 kW KV Range 40–110 kV 40–125 kV 40–125 kV mAs Range 0.2–200 mAs 0.1–200 mAs 0.1–200 mAs mA Range 20–100 mA 10–100 mA 10–100 mA Working Frequency ≥40 kHz ≥40 kHz ≥40 kHz Communication Mode RS232 RS232 RS232 Exposure Time 0.01–4 s 0.01–4 s 0.01–4 s Exposure Mode Hand brake, wireless remote, touchscreen Hand brake, wireless remote, touchscreen Hand brake, wireless remote, touchscreen X-ray Tube Parameters
-
Anode Heat Storage: 56 KHU
-
Focal Spot: 1.8 mm
-
Anode Angle: 15°
-
Inherent Filtration: 1.2 mm Al @ 75 kV
Collimator
-
Power Supply: AC/DC 24V ±10%
-
Light Type: LED 5 W
-
Light Delay Time: 30 ±2 s
-
Illumination: ≥160 Lux
Flat Panel Detector (Iray Venu1717X)
-
Dimensions: 460 × 460 × 15 mm
-
X-ray Energy: 40–150 kV
-
Scintillator: CsI:Tl
-
Pixel Size: 139 μm
-
Fill Factor: 70%
-
Effective Array: 3072 × 3072
-
Effective Area: 427 × 427 mm
-
Spatial Resolution: ≥3.4 lp/mm
-
Image Transfer: Gigabit Ethernet
Workstation (Dell Vostro 15-3520)
-
Processor: Intel Core i5-1135
-
OS: Windows 11 Home
-
Graphics: Intel UHD Graphics
-
RAM: 32 GB DDR4
-
Storage: 512 GB SSD
-
Display: 15.6" Full HD (1920 × 1080)
-
Net Weight: 1.69 kg
-
Thickness: 16.96 mm
Dimensions & Weight
Unit Main Head Unit (mm) Net Weight (kg) Head Screen PXD01 290 × 265 × 230 19 10.4" LCD PXD02 425 × 240 × 220 18 10.4" LCD PXD03 425 × 240 × 220 18 10.4" LCD -
Trolley Height Adjustable Range: 515–1810 mm from spot to floor
Applications
-
Hospitals and clinics: Emergency room, OR, ICU, Orthopedics
-
Mobile and field diagnostics
-
Veterinary and animal hospitals
-
Sports medicine, physical examination, rural medical visits
The SHO-PXD Series combines deluxe mobility, high-resolution imaging, and integrated workstation functionality, making it an ideal solution for advanced portable X-ray imaging.
-
