Labmate Stereo Microscope LMSM-608
Labmate Stereo Microscope LMSM-608 features a 45° inclined binocular viewing head with an interpupillary distance of 55–57 mm for comfortable observation. It utilizes a 0.6×–5× zoom objective with a 1:8.3 zoom ratio and an extra wide-field EWF10×/23 eyepiece with independent focus adjustment. The 125 mm diameter glass stage supports both incident and transmitted LED illumination integrated into a slim base, enabling clear, high-contrast, three-dimensional imaging.
Product Info
Key Features
-
Binocular head inclined at 45° with interpupillary adjustment 55–57 mm
-
Zoom objective 0.6×–5× with 1:8.3 zoom ratio
-
Extra wide-field EWF10×/23 eyepiece with independent focus
-
125 mm glass stage compatible with incident and transmitted LED illumination
-
Rack and pinion focusing mechanism for precise control
-
Bright, long-life LED illumination
-
Ergonomic design with ample working space
Technical Highlights
Specification Details Viewing Head Binocular, 45° inclined Interpupillary Distance 55–57 mm Objective Zoom 0.6×–5× Eyepiece EWF10×/23 Zoom Ratio 1:8.3 Working Distance 115 mm Focusing Range 105 mm Stage Insert Glass plate 125 mm diameter, Opal & black acrylic plate 125 mm Illumination Incident/transmitted LED, 100–240 V Video Adapter 0.55× C-mount Applications
Labmate LMSM-608 is ideal for industrial production, quality control, materials research, forensics, biotechnology, genetics, and biomedical research where high-resolution stereo imaging and ergonomic operation are required.-
