Shoimage SHO-FPD05 Wireless Flat panel detector
The Shoimage SHO-FPD05 Wireless Flat Panel Detector is a cutting-edge device designed for a range of medical uses, providing superior image quality and reliability in diagnostic imaging. As an authorized distributor, Winselluma ensures you receive genuine and high-performance products to enhance your medical facility's efficiency and patient care. Streamline your workflow with this portable and easy-to-use detector, perfect for various clinical environments. Trust Winselluma for unparalleled service and support, delivering exceptional value to medical professionals.
Product Info
SHO-FPD05 Wireless Flat Panel Detector
A high-performance wireless amorphous silicon (a-Si) flat panel detector with CsI scintillator, designed for digital radiography in both human and veterinary applications, offering flexibility and mobility without tethered cables.
Technical Specifications
Sensor & Imaging Technology
Parameter Specification Sensor Type a-Si (Amorphous Silicon) Scintillator CsI Effective Imaging Area 43 × 43 cm (17×17 inch) Active Matrix 3072 × 3072 Effective Pixel Pitch 139 µm A/D Conversion 16 bits Spatial Resolution 3.6 LP/mm Image Acquisition Time 2.5 s X-ray Working Power 40–150 kV Wireless & Connectivity
Parameter Specification Data Interface GigE / 802.11n/ac Battery Standby Time 7 hours Power Consumption 20 W Adapter Input AC 100–240 V, 50–60 Hz Adapter Output DC 24 V, 60 W Mechanical & Build
Parameter Specification Dimensions (L × W × H) 46 × 46 × 1.5 cm Weight 3.7 kg Housing Material Carbon fiber + Alloy Environmental
Parameter Specification Operating Temperature 5–35°C Operating Humidity 10–75% RH Storage Temperature -20–55°C Storage Humidity 10–75% RH Waterproofing Grade IP54 ✅ Key Highlights:
-
Wireless operation with up to 7 hours battery life for maximum mobility.
-
High spatial resolution (3.6 LP/mm) and large imaging area (43×43 cm).
-
Lightweight (3.7 kg) and robust (carbon + alloy housing).
-
Flexible connectivity: Gigabit Ethernet or Wi-Fi (802.11n/ac).
-
Rugged design with IP54 waterproofing for clinical and veterinary use.
-
