Infitek Muffle Furnace, 1400℃ High Temp, TubeHorizontal Type, FNC-TB1400 Series
- Experience precision and reliability with the Infitek FNC-TB1400 Muffle Furnace.
- Offers a max. temp. of 1400℃ for short periods.
- Continuous temp. of ≤1300℃, ensuring versatility.
- Chamber made from high-grade alumina ceramic fiber.
- Excellent thermal insulation and durability.
- Heating rate of 0~20℃/min (suggested 0~10℃/min).
- Guarantees controlled, efficient heating.
- Trust the superior performance of the Infitek Muffle Furnace for high-temp applications.
Product Info
Key Features
1400°C maximum operating temperature;
PID automatic control via current limiting phase angle fired the resistor, e.g. SC R (Silicon Controlled Rectifier);
30 or 50 segments “time-temperature curve” can be set arbitrarily.
Tube furnace using high purity quartz or alumina tube as a furnace tube, furnace tube design with horizontal installation, vertical installation.
Temperature zone is designed with single-zone, dual-zone, three-zone, five-zone and so on. Furnace also increase the rotational tilt system.Safety
Double layer steel structure with air cooling fan to keep furnace’s exteriors safe to touch;
Safety interlock with automatic power off the furnace when door is opened;Optional
Different chamber size for your choose.
Touch screen (with USB interface)
Computer connection software, control equipment (RKC, 16-segment program + interface + software)
Note: You can only choose one between 2 and 3;
