Labmate Automatic Thermogravimetric Analyzer LMTGA-A100
The Labmate Automatic Thermogravimetric Analyzer LMTGA-A100 is a high-precision instrument for studying thermal stability, decomposition, adsorption, and phase transitions. It operates from room temperature up to 1250 ℃, utilizing K- or E-type sensors with dual temperature monitoring for both furnace and sample. The built-in weighing balance includes internal calibration and temperature compensation to ensure stable and accurate measurements. A dual gas path structure provides airtight experimental conditions.
Product Info
Key Features
-
PID temperature control for precise heating and stability
-
Touchscreen display for intuitive operation
-
Independent atmosphere control for controlled experiments
-
Data logging system with PC software integration
-
Ceramic-insulated furnace for uniform temperature distribution
Applications
Suitable for analyzing thermal stability, decomposition, adsorption, and phase transitions in polymers, pharmaceuticals, metals, composites, and catalysts.Technical Highlights
Parameter Specification Temperature Range Room temperature to 1250 ℃ Temperature Control Heating, constant temperature, cooling Temperature Resolution 0.01 ℃ Temperature Fluctuation ±0.01 ℃ Heating Rate 0.1–100 ℃/min Measurement Range of Balance 0.01 mg to 5 g Mass Resolution 0.01 mg DSC Range 0 to ±2000 mW DSC Sensitivity 0.001 mW Constant Temperature Time 0–500 min Cooling Time 20 min Toggle Rate 16.6 Hz Sample Rate 0.05–10 Hz, programmable Experimental Mode FTC and STC Experimental Type Weight loss, weight gain (adsorption) Program Temperature Control 12 stages Power Supply 220 V, 50 Hz Dimensions (L × W × H) 400 × 350 × 200 mm Weight 40 kg -
