Excellent mixing result.
Stable and wide range of speed adjustment.
Precise temperature control for heating and cooling.
Flexible adapter selection.
Programmable.
Compatible with various tubes.
Quick interchange of blocks with magnet adhesion technology without any tools.
Block equipped with a lid for heat preservation.
Three-point temperature calibration.
SPECIFICATIONS
Specifications | DBI-RS100 | DBI-S100 | DBI-100III |
Functions | Heating, cooling & mixing | Heating & mixing | Heating |
Temperature range | Heating: room temp.-100℃ Cooling: room temp.-below room temp. 15℃ | Heating: room temp. -100℃ | Heating: room temp.+5℃-100℃ |
Temperature setting range specifications (℃) | 0.1~100 | 15~100 | 15~100 |
Temperature control accuracy (@20-45℃) | ±0.5℃ | ±0.5℃ | ±0.5℃ |
Temperature uniformity (@20-45℃) | ±0.5℃ | ±0.5℃ | ±0.5℃ |
Max. heating rate | 5.5℃/min | 5.5℃/min | 5.5℃/min |
Max. cooling rate | 5℃/min(100℃-room temp.) 0.5℃/min (below room temp.) | – | – |
Mixing frequency | 200rpm-1500rpm | 200rpm-1500rpm | – |
Mixing orbit | 3 mm | 3 mm | – |
Time setting range | 0~99h30min | 0~99h30min | 0~99h30min |
Program | 9 | 9 | 9 |
Overheating protection | 150℃ | 150℃ | 150℃ |
Display | TFT | TFT | TFT |
Adapter block material | aluminum | aluminum | Aluminum |
Voltage, Frequency | 100V-240V, 50Hz/60Hz | 100V-240V, 50Hz/60Hz | 100V-240V, 50Hz/60Hz |
Power | 200 W | 200 W | 200 W |
Dimension (W×D×H) (without the heating block) | 200mm×235mm×120mm | 200mm×235mm×120mm | 200mm×235mm×120mm |
Weight | 7.3 kg | 7.3 kg | 7.3 kg |
Package Dimension (W*D*H)(mm) | 420mm×390mm×250mm |
Accessories & Package
