Labmate Soil Nutrient Tester LMSNT-A100
The Labmate Soil Nutrient Tester LMSNT-A100 accurately measures key soil nutrients to help optimize crop yield and soil health. Available through winselluma, an authorized distributor, this device delivers reliable results for agronomists, farmers, and soil scientists. Designed for ease of use and precision, it supports informed decision-making in soil management. Trust winselluma for professional-grade tools backed by expert service and support. Enhance your soil testing capabilities with this trusted solution from a recognized distributor.
Product Info
Labmate Soil Nutrient Tester LMSNT-A100
Product Overview
The Labmate Soil Nutrient Tester LMSNT-A100 is a comprehensive, multi-functional analytical instrument designed for rapid on-site and laboratory soil health assessment. It features a microcomputer control system that automates the detection of macronutrients (N, P, K), organic matter, pH, and salinity. Beyond standard nutrients, it is capable of identifying trace elements and heavy metals in soil, plants, and fertilizers. With a built-in thermal printer and dual power support (AC/DC), the LMSNT-A100 is an essential tool for fertilizer optimization, crop management, and environmental monitoring.
Technical Specifications
Category Parameter Specification Measurement & Accuracy Measurement Range 0.001 to 9999 Resolution 0.001 Repeatability Error ≤ 0.05% Linear Error ≤ 0.2% Stability Drift ≤ 0.2% (30 min); ≤ 0.3% (1 hr); ≤ 0.5% (2 hrs) Detection Capabilities Soil Nutrients N, P, K, Organic Matter, pH, Salt Content Trace Elements Ca, Mg, S, Fe, Mn, B, Zn, Cu, Cl, Si Heavy Metals Pb, Cr, Cd, Hg, As Fertilizer Types Chemical, Organic, Foliar, Water-soluble Water Quality pH and same trace elements listed above Optical System Wavelengths Red (680nm), Blue (420nm), Green (510nm), Orange (590nm) pH Range 1 to 14 Salt Content 0.01% to 1.00% (Conductivity) Operational Specs Test Speed 1 sample: ≤ 30 min; 8 samples: ≤ 1 hr Display LCD with Touch Key Operation Data Storage Integrated Memory Storage Printer Built-in Thermal Printer General Power Supply AC 220V / DC 12V (Vehicle or Lithium Battery) Power Consumption ≤ 5W Weight / Dimensions 5 kg / 550 × 390 × 370 mm Key Features
-
Comprehensive Nutrient Profiling: Detects a wide spectrum of elements from primary macronutrients to 10 different trace elements.
-
Heavy Metal Screening: Equipped to test for hazardous heavy metals like Lead, Mercury, and Arsenic, ensuring soil safety.
-
High Efficiency Testing: Capable of processing 8 samples simultaneously within an hour, significantly reducing downtime.
-
Integrated Thermal Printer: Allows for immediate, one-touch printing of test results for record-keeping in the field.
-
Stable Light Source: Uses a multi-wavelength optical system (Red, Blue, Green, Orange) to ensure precise colorimetric analysis.
-
Dual-Power Versatility: Can be powered via standard AC, vehicle power, or its internal lithium battery, making it truly portable for remote agricultural sites.
Applications
-
Precision Agriculture: Guiding fertilizer application rates to prevent over-fertilization and reduce costs.
-
Agricultural Research: Assessing the impact of different farming practices on soil fertility and trace element levels.
-
Soil Remediation: Monitoring heavy metal concentrations in contaminated land or industrial sites.
-
Nursery & Greenhouse Management: Daily monitoring of water quality and soil moisture (0–100% range).
Optional Accessories (Reagents)
To perform the full range of tests, the following optional reagent kits are available:
-
LMSNT-A100-S1: Soil organic matter reagent.
-
LMSNT-A100-S2: Trace element reagents (Ca, Mg, S, Fe, Mn, B, Zn, Cu, Cl, Si).
-
LMSNT-A100-S3: Heavy metal reagents (Pb, Cr, Cd, Hg, As).
-
LMSNT-A100-S4: Pretreatment reagents for Total N, P, and K.
-
